Drilling Engineering and Operations
Following the preparation stage of field development i.e., setting the production strategy, determining the locations of the wells in the field, and designing the well completions, the drilling-related activities begin. The drilling program is first designed.
Then, plans are prepared and executed to acquire
the required equipment and materials. The drilling sites in the field are then
prepared for the equipment and materials to be moved in, and the drilling
operations begin. Depending on the organization of activities within the oil
company, drilling engineers may only be responsible for drilling and casing of
the well, and production engineers will be responsible for completion of the
well.
Alternatively,
drilling engineers may be responsible for drilling and completion of the wells.
The drilling program consists of three main stages: (1) drilling the hole to
the target depth, (2) setting the various casings, and (3) cementing the
casing.
Whether onshore
or offshore drilling is carried out, the basic drilling system employed in both
the cases will be the rotary rig. The parts of such a unit and the three basic
functions carried out during rotary drilling operations are as follows:
Torque is
transmitted from a power source at the surface through a drill string to the
drill bit. A drilling fluid is pumped from a storage unit down the drill string
and up through the annulus.
This fluid will bring the cuttings created by
the bit action to the surface, hence clean the hole, cool the bit and lubricate
the drill string.
The subsurface
pressures above and within the hydrocarbon-bearing strata are controlled by the
weight of the drilling fluid and by large seal assemblies at the surface
(BOPs).
However, in
practice, onshore and offshore drilling units are often quite different in
terms of technology and degree of automatization.
This is largely
driven by rig availability, costs and safety considerations. We will now
consider the rotary rig in operation, visiting all elements of the system.
The type of rig
operation described first is now found mainly in low-cost onshore areas.
For complicated, more expensive wells, older
rigs have usually been upgraded to include a top drive system and automated
pipe handling. New rigs are usually built with this equipment as standard.
When drilling
through normally pressured formations, the mud weight in the well is usually
controlled to maintain a pressure greater than the formation pressure to
prevent the influx of formation fluid.
A typical overbalance would be in the order of
200 psi. A larger overbalance would
encourage excessive loss of mud into the formation, which is both costly, and
may damage the reservoir properties.
If an influx of
formation fluid into the borehole did occur due to insufficient overbalance,
the lighter formation fluid would reduce the pressure of the mud column, thus,
encouraging further influx, and an unstable situation would occur, possibly
leading to a blowout. Hence, it is important to avoid the influx of formation
fluid by using the correct mud weight in the borehole.
When drilling
through a shale into an over pressured formation, the mud weight must be
increased to prevent influx. If this increased mud weight would cause large
losses in shallower, normally pressured formations, it is necessary to isolate
the normally pressured formation behind casing before drilling into the over
pressured formation.
The prediction
of overpressures is therefore important in well design. Similarly, when
drilling into an under pressured formation, the mud weight must be reduced to
avoid excessive losses into the formation.
If the rate of
loss is greater than the rate at which mud can be made up, then the level of
fluid in the wellbore will drop and there is a risk of influx from the normally
pressured overlying formations.
Problems can be
encountered in the drilling of any hole at any time; and drilling personnel
must be aware of this fact and of the symptoms that indicate the various types
of problems.
On the other hand, many problems can be
avoided or minimized by proper planning. Geological information and the
experience gained from drilling previous wells in the same area can be used to
predict the existence of problem zones, and such data should certainly be used
to the fullest extent.
However,
problems encountered in one well may not exist in the immediate vicinity, while
new problems can arise at any time. Such
is the nature of drilling a small hole to great depths through often heterogeneous
layers of subsurface rock.
After the shale
site construction, the drilling rig is moved on site and assembled. A conductor
hole is predrilled, and then conductor pipes are inserted to prevent soft rocks
from caving and conduct drilling mud from bottom to the surface during drilling
process.
Depending on the number, depth, and length of
horizontal wells to be drilled, the drilling
stage can last for a few months, which requires a constant supply of drilling
fluid and proper handling of sediments and wastewater.
Once the
drilling is completed, protective casing and cementing are used. The following
stage is the well completion, which mainly involves the hydraulic fracturing
operation.
A mixture of water, sand, and chemical
additives is injected underground at a high pressure to break up shale-rock
formations, such that fractures are created and held open by proppant, and then
shale gas and oil can be extracted.
Typically, the horizontal wells are stimulated
by stages, depending the specific fracturing schedule and technology applied,
the hydraulic fracturing stage could last for several months.
Once fracturing
is completed, a wellhead is constructed, and the local gathering pipelines are
prepared for the controlled extraction of natural gas.
